model | IGrid VE 5.5K-48V |
Maximum PV array power | 5500W |
Rated output power | 5500W |
MPPT range and working voltage | 120-450VDC |
Rated output voltage | 220/230/240VAC |
Output voltage range | 184-265VAC |
Rated output current | 20.5A/19.6A/18.8A |
efficient | up to 93% |
Acceptable input voltage range | 120-280VAC |
Frequency Range | 50Hz/60Hz (self-adaptive) |
Rated output voltage | 220/230/240VAC |
Output waveform | Pure sine wave |
Rated DC voltage | 48VDC |
Maximum AC charging current | 60A |
Maximum charging current (AC + PV) | 90A |
Maximum output power | 5500W |
Surge power | 11000W |
Automatic conversion time | <10ms |
Parallel function | Yes |
communication | USB or RS232, WIFI, generator dry contact |
humidity | 0~90% RH (non-condensing) |
Operating temperature | 0 to 50 ℃ |
Net weight (KG) | 11.35 |
Gross weight (KG) | 12.35 |
Dimensions (length x width x height) mm | 295x468.6x120.2 |
